Terex Manlift Specifications
Based in Westport, Connecticut, Terex specializes in manufacturing construction machines. They make machines such as manlifts, boom lifts and aerial lifts. These kinds of machines are designed to facilitate access to places that are hard to reach, large equipment, buildings and roofs, among other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration refers to a power-driven endless belt. This belt only moves in one direction and includes platforms, or steps or handholds which are attached to the unit to be able to transport personnel from every floor.
TB85
The TB85 man lift by Terex offers a max working height at 91 feet. The platform's max height reaches 85 feet, while the model's maximum width is 8.5 feet. The TB85 has dimensions which measure 9 feet, 1-inch high and 9 inches wide by 36 feet. This model provides a reach of seventy feet. The TB85 has a boom angle above horizontal reaching 75 degrees and below horizontal measures at -14 degrees.
Terex TB100
The Terex TB100's maximum working height is 106 feet and the maximum height of the platform is 100 feet. When the TB100 is stowed it is 9 feet high by 8 feet, 1 1/2 inches wide by 8 feet. The unit's maximum width is 8 feet, 1 1/2 inches. The boom angle above horizontal is 75 degrees and below horizontal is 14 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The Terex TB110 man lift reaches a max height of 100 feet, while the max working height measures at 116 feet. The model is 9 feet, 4 inches high x 8 feet wide when stowed away. The TB110 offers a horizontal reach of 67 feet and a maximum width of 8 feet. This model has a boom angle of 75 degrees above horizontal plus ten degrees articulating. Below horizontal it is -14 degrees and it measures -105 degrees articulating.
